Powerful Electric Wire Making Machine / PVC Cable Extrusion Machine

Brand Name : Fuchuan

Model Number : FC-70+40-6

Certification : ISO9001:2008

Place of Origin : China JiangSu

MOQ : 1set

Price : NEGOTIABLE

Payment Terms : T/T, L/C

Supply Ability : 500 SETS PER YEAR

Delivery Time : 45days

Packaging Details : normal packing

color : sky blue

pay off bobbin : DIAMETER 500/630/800/1000mm

fit for wire : BV,BVR,RV,PE,BVV

wire : enamelled wire/glazed wire/insulated wire

BV building wire : also LAN cable

Wire Dia : 1.5-12mm

plastic material : PVC/PE

screw dia : 50/60/70/80/90

Contact Now

Powerful Electric Wire Making Machine / PVC Cable Extrusion Machine

Electric Wire Making Machine Quick Details:

BV,BVV,BVR,RV Electric Wire Making Machine

1. Apply for extruding the PVC,PE and other plastic material for the BV,BVR insulate sheathing produced.

Electric Wire Making Machine Characteristics:

2.1 PLC+IPC operation or touch screen operation, save, display and change all kinds technological parameters. Whole-process monitor.

2.2 Superior special non-adjusted head, meet the extruder technological parameters requirement.

2.3 High speed pay off equipment, assure unload the bobbin do not stop machine.

Electric Wire Making Machine Specification:

Model FC-60 FC-70-6 FC-80
Screw Diameter Φ60 Φ70 Φ80
Screw L/D Ratio 26:1 26:1 25:1
Feed wire type Active pay off or tension pay off
Max speed(m/min) 300 300 200
Extrusion output 100 150 200
Power for main machine(KW) 18.5 30 37
Wire diameter Φ0.8-8.0 Φ1.5-12 Φ5.0-20
Max accumulator length(m) 220
Accumulator Horizonal accumulator
Cooling channel Folding W type or U type
Capstan diameter Φ410 Φ510 Φ610
Capstan power 3.7KW 5.5KW 7.5KW
Take up power 5.0KW 7.5KW 3.7KW reduction motor
Take up type Double shaft take-up

Other Information

FOB SHANGHAI
Payment

TT, L/C
Delivery

FOB Shanghai/Ningbo
Origin

China
Minimum Order

1 set
Package
with container
